HONEYWELL Balancing Value 2 Way รุ่น V5CF SERIES

Features

• In this balanced valve design, the constant flow cartridge moves up and down with system pressure fluctuating to keep the flow constant.
• No power need in the constant flow modulating.
• Every loop automatically limited to design flow
• Robusting design save the installation space.
• Simplied pipe design and calculation
• Quick and easy setup
• No balancing debug work required
• Stainless steel valve stem resists corrosion & long service life

Specifications

• Size Range: DN50～500(2″～ 20″)
• Flow Precision: 5%
• Pressure Rating: Static 375 psi (25 Bars),
• Burst 1875 psi (125 Bars)
• End Connections: Compatible with DIN EN 1092-1 2002 steel flanges
• Medium: water
• Media temperature: 0～ 110℃
• Valve Material: Body of ductile iron
  Cartridge of stainless steel
  O-ring seals of EPDM
• Operating ambient temperature: 0 to 65°C
• Shipping & storage temperature:-40 to +65°C
• Atmosphere: non-corrosive, non-explosive
• Dimensions: See Diagram
