TASCO แวคคั่มปั๊ม Vacuum Pump Single Stage 3 CFM รุ่น TB43CS

TASCO แวคคั่มปั๊ม Vacuum Pump Single Stage 3 CFM รุ่น TB43CS

Specification

• Model : TB43CS
• Rotor system : Single stage
• Motor : AC
• Drive method : Direct type
• Displacement : 83 l/min (3 CFM)
• Ultimate vacuum : 150 microns
• Motor 2,880 RPM
• Power supply, motor : 220V/50 Hz
• Suction port : 1/4″, 3/8″ SAE MALE
• Amount of oil filled : 180 ml.
• Operating temperature : 5~40°C
• Size : 100 x 280 x 215 mm.
• Weight : 5 kg.
